Physical Characteristics |
|
|
Dimensions |
160.0 x 76.0 x 15.5 mm / 6.3 x 2.99 x 0.61 in |
|
Weight |
287 g / 10.12 oz. (device with battery) |
|
Display |
5.2'' IPS FHD 1920 x 1080 |
|
Touch Panel |
Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
|
Power |
Main battery: Li-ion, rechargeable, 5000 mAh
Standby: over 350 hours
Continuous use: over 12 hours (depending on user environment)
Charging time: 3-4 hours (with standard adaptor and USB cable)
|
|
Expansion Slot |
1 slot for SIM card, 1 slot for SIM or TF card |
|
Interfaces |
Android 9.0: USB Type-C, USB 3.0, OTG, extended thimble; Android 11.0: USB Type-C, USB 3.1, OTG, extended thimble; |
|
Keypad |
4 front keys, 1 power key, 2 scan keys, 1 multifunctional key |
|
Developing Environment |
|
|
Operating System |
Android 9.0; GMS, 90-day security updates, Android Enterprise, ZeroTouch, FOTA, Soti MobiControl, SafeUEM supported Android 11.0; GMS, built-in support for a future upgrade through Android 12 which complies with GMS and Android Enterprise Recommended |
|
SDK/tool |
Java/Eclipse / Android Studio |
|
WLAN |
IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna |
|
Wan |
WWAN (China):
2G: 900/1800MHz
3G: WCDMA: B1,B8
CDMA2000 EVDO: BC0
TD-SCDMA: B34,B39
4G: B1,B3,B5,B8,B34,B38,B39,B40,B41
WWAN (Europe):
2G: 850/900/1800/1900 MHz
3G: B1/B2/B4/B5/B8
4G: B1/B3/B5/B7/B8/B20/B40
WWAN(America):
2G: 850/900/1800/1900 MHz
3G: B1/B2/B4/B5/B8
4G: B2/B4/B7/B12/B17/B25/B66
Android 11.0:
2G: GSM850/GSM900/DCS1800/PCS1900
3G: WCDMA：B1/B2/B4/B5/B8
CDMA2000 EVDO: BC0
TD-SCDMA：A/F
4G:B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28A
B28B/B34/B38/B39/B40/B41
|
|
Communication |
|
|
Bluetooth |
Android 8.1: Bluetooth v2.1+EDR,3.0+HS,v4.1+HS
Android 11.0: Bluetooth 5.0
|
|
GNSS |
GPS/AGPS, GLONASS, BeiDou; internal antenna |
|
Performance |
|
|
CPU |
Cortex-A53 2.5 / 2.3 GHz Octa-core |
|
RAM+ROM |
3GB + 32GB
4GB + 64GB (optional)
|
|
Expansion |
Supports up to 128 GB Micro SD card |
|
UHF RFID (This function is optional) |
|
|
Frequency |
865-868 MHz / 920-925 MHz / 902-928 MHz |
|
Protocol |
EPC C1 GEN2 / ISO18000-6C |
|
Antenna |
Circular polarization (1 dBi) |
|
R/W ranges |
Up to 3m (depend on tags and environment) |
|
2D Imager Scanner |
Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603 |
|
1D Linear Scanner |
Zebra: SE965; Honeywell: N4313 |
|
1D Symbologies |
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
|
2D Symbologies |
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. |
|
NFC/HF ( This function is optional) |
|
|
Frequency |
13.56 MHz |
|
Protocol |
ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. |
|
Chips |
M1 card (S50, S70), CPU card, NFC tags, etc. |
|
Range |
2-4 cm |
